PWR-F-RS485-CS
802.11 b/g/n Wi-Fi Module OEMs, Tx-Rx, Client / Server type, RS485 transceiver, led Wi-Fi flashing
Ordering Code: PWR-F-S04-CS [add_to_cart sku=PWR-F-S04-CS]
PWR-F-RS485-CS is a client / server type Wi-Fi module: this means that it is able to autonomously connect to a server, also public, and communicate with it. It can simulate a wire cutting between two devices used combined with a PWR-F-RS232-S module.
Like other Compact modules it permits ad hoc mode and infrastructure operation mode.
TRANSCEIVER AND POWER SUPPLY
Wiicom supplies a solution for the transceiver needs that combines powering and interfacing. PWR-F-RS485-CS is equipped with a RS485 transceivers to communicate with the host.
In addition it can ben supplied with a voltage between 7 and 28Vdc, for an industrial and all-day use.
CLOUD READY
PWR-F-RS485-CS client/server versions are able to connect directly to many servers, also with public ips, and start a communication with them. In addition they are able to make a connection with a Cloud service, like Wiicom Sense Cloud.
NO SOFTWARE NEEDED
The PWR-F-RS485-CS modules are immediately ready to be used. Thanks to Wiicom configurator software, available on wiicom website, user can define all Wi-Fi network settings.
There’s no need to develope or modify any software on the host board.
